2700mm Paper Industry Overfeed Rewinder
This 2700mm overfeed rewinder is designed as a coreless, dual-drum, single-drive unit. It is used to process full-width paper rolls—originally wound on a paper machine—by unwinding them and rewinding them into finished rolls with specific widths, diameters, and tightness levels. The 2700mm overfeed rewinder is primarily intended for high-strength corrugated medium, accommodating a basis weight range of 80–220 g/m². It operates at a speed of 800 m/min, with a maximum finished roll width of 2700 mm, a maximum parent roll diameter of φ2800 mm, and a maximum finished roll diameter of 1500 mm. It supports a maximum of three-roll slitting (using four knives) and utilizes paper cores with an inner diameter of 3 inches (76.2 mm). This 2700mm overfeed rewinder employs a constant-tension AC variable-frequency control system. The unwind roll utilizes indirect tension control to maintain a constant web tension, with rotational inertia compensation applied during acceleration and deceleration phases. The 2700mm overfeed rewinder also features automatic stop functions based on a preset roll diameter or length, automatic deceleration when the unwind roll diameter falls below a specified value, automatic stopping in the event of a web break or paper depletion, and an automated fault detection and alarm system. Leizhan...
